S09
Deepal
5-door 6-seat SUV
▍Technical Parameters
| configuration parameter | RWD Max / RWD UItra / RWD UItra+ | 4WD UItra / 4WD UItra+ |
| Length x width x height (mm) | 5205x1996x1800 | |
| wheel base(mm) | 3105 | |
| Front/rear wheelbase (mm) | 1690/1700 | |
| Number of seats | 6 seats | |
| Shift mode | Electronic gearshift lever | |
| Maximum speed (km/h) | 205 | |
| Luggage compartment capacity (L) | 427-1392 | |
| Storage space under the trunk lid | 44L(20-inch suitcase) | |
| motor | Extended-range 314 horsepower | Extended-range 492 horsepower |
| Pure electric range (km)WLTC | 180 | 170 |
| Pure electric driving range (km)CLTC | 220 | 210 |
| Combined range (km)WLTC | 972 | 927 |
| Combined range (km)NEDC | 1120 | 1066 |
| Charging time (hours) | Fast charging takes 0.25 hours and slow charging takes 6 hours | |
| Fast charging capacity (%) | 30-80 | |
| Maximum power (kW) | 231(314Ps) | 362(492Ps) |
| Maximum torque (N·m) | 375 | 637 |
| speed changing box | Single-speed transmission for electric vehicles | |
| Official 0-100 km/h acceleration time (seconds) | 7.9 | 5.9 |
| WLTC combined fuel consumption (L/100km) | 0.83 | 0.91 |
| Power consumption per 100 kilometers (kWh/100km) | 22.2 | 23.3 |
| Fuel consumption equivalent to electric energy (L/100km) | 2.58 | 2.71 |
| Minimum state of charge fuel consumption (L/100km)WLTC | 6.6 | 6.9 |
| Minimum state of charge fuel consumption (L/100km)NEDC | 5.6 | 5.9 |
| Curb weight (kg) | 2590 | 2668 |
| Full-load mass (kg) | 3080 | 3180 |
| Fuel tank capacity (L) | 50.0 | |
| minimum turning radius | 5.85m | 5.8m |
| Coefficient of wind resistance (Cd) | 0.283 | |
| Displacement (mL) | 1497 | |
| Intake form | turbocharging | |
| Engine layout form | be held horizontally | |
| Maximum horsepower (Ps) | 150 | |
| Maximum power (kW) | 110 | |
| Maximum net power (kW) | 105 | |
| Maximum power rotational speed (rpm) | 5000 | |
| Maximum torque (N·m) | 220 | |
| Maximum torque speed (rpm) | 3200-4200 | |
| Engine thermal efficiency (%) | 44.28 | |
generator style | Permanent magnet/synchronous | Front AC/asynchronous, rear permanent magnet/synchronous |
| Total power of the motor (kW) | 231 | 362 |
| Total horsepower of the motor (Ps) | 314 | 492 |
| Total torque of the motor (N·m) | 375 | 637 |
| Number of drive motors | single motor | dual-motor |
| Motor layout | postposition | Front camera + Rear camera |
Battery Type | lithium iron phosphate battery | |
| Battery capacity (kWh) | 40.18 | |
| Battery energy density (Wh/kg) | 125.0 | |
| Front suspension form | Double wishbone independent suspension | |
| Rear suspension form | Multi-link independent suspension | |
Diversionary Mode | electric powe | |
| Front/rear brake type | Vented Disc | |
| Tire size | 255/50 R20 | 255/50 R20/265/45 R21 |
▍Company Profile
Guangzhou Meilun Auto Co.,Ltd. was established in June 2001.
With more than 24 years of focusing on cars sales and maintenance services, Guangzhou Meilun Auto is proud to be a Top 100 car dealer in the China Automobile Dealers Association.
The Company is an authorized dealer of GAC Trumpchi, GAC AION, Hyptec, IM, Rising, SAIC ROEWE, SAIC MG, LeapMotor, Geely, Geometry, SAIC-GM Buick, and Haval. The Company has gained many awards from the manufacturers for our excellent sales and high customer satisfaction rating.
We have a well portfolio of Chinese cars, SUV, MPV, coupe (PHEV, Hybrid, EV, gasoline cars) and therefore we will have the perfect vehicle you might feel of interest. In particular, our Trumpchi and AION are the Top 10 dealers for nationwide.
▍Product Produce
▍Exhibition
▍Cooperative Client
▍FAQ
1. How can I get the price?
-We usually quote within 24 hours after we get your inquiry (Except weekend and holidays).
-If you are very urgent to get the price, please email us or contact us in other ways so that we can offer you a quote.
2. Can I buy samples placing orders?
-Yes. Please feel free to contact us.
3.What is your lead time?
-It depends on the order quantity and the season you place the order. -Usually we can ship within 7-15 days for small quantity, and about 30 days for large quantity.
4. What is your payment term?
-T/T, Western Union, MoneyGram, and Paypal. This is negotiable.
5. What is the shipping method?
-It could be shipped by sea, by air or by express (EMS, UPS, DHL, TNT, FEDEX and ect). Please confirm with us before placing orders.
6. How do you make our business long-term and good relationship?
-1. We keep good quality and competitive price to ensure our customers benefit;
-2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
